16F877A

TIENE PINES PARA
1. ENTRADAS ANALOGICAS
2. ENTRADAS Y SALIDAS DIGITALES
3. CONEXION PARA EL OSCILADOR EXTERNO
4. CONEXION PARA PROGRAMACION ICSP
5. PUERTOS ESCLAVOS PARALELOS
6. INTERRUPCIONES EXTERNAS
TIENE UNA MEMORIA DIVIDIDA EN BANCOS
1. LOS BANCOS TIENEN REGISTROS DE PROPOSITO GENERAL
  1. Y REGISTROS DE PROPOSITO ESPECIAL
    1. COMO EL REGISTRO DE STATUS
      1. SIRVE PARA VER EL STATUS ARITMETICO DE LA ALU
TIENE UN TEMPORIZADOR/CONTADOR CON
1. REGISTRO DE 8 BITS
2. LECTURA/ESCRITURA
3. SELECCION DE RELOJ INTERNO O EXTERNO
4. INTERRUPCION DE DESBORDAMIENTO DE 00H A FFH
